Original NACHI 7338BDT bearing

Original NACHI 7338BDT bearing

Contact us for a quote
Availability: In Stock

This NACHI 7338BDT bearing is the original product, with best price, fast delivery and best quality. The bearing's dimensions are 190x400x78. NACHI Angular Contact Ball Bearing: Correspond to the design...

Size: 190x400x78

Model: 7338BDT

Bearing 7338BDT

Angular contact ball bearings 7338BDT

Bearing number : 7338BDT

Size (mm) : 190x400x78

Brand : NACHI

Bore Diameter (mm) : 190

Outer Diameter (mm) : 400

Width (mm) : 78

Bearing dimensions and specification in NACHI catalogue:

d - 190 mm

D - 400 mm

B - 78 mm

C - 78 mm

Angle (α) - 40 °

a - 84.8 mm

r min. - 5 mm

r1 min. - 2 mm

2B - 156 mm

da min. - 200 mm

Da max. - 390 mm

ra max. - 2 mm

Weight - 47.6 Kg

Basic dynamic load rating (C) - 680 kN

Basic static load rating (C0) - 1150 kN

(Grease) Lubrication Speed - 1000 r/min

(Oil) Lubrication Speed - 1400 r/min

Original NACHI 7338BDT bearing warehouse image1 Original NACHI 7338BDT bearing warehouse image2 Original NACHI 7338BDT bearing warehouse image3 Original NACHI 7338BDT bearing package Original NACHI 7338BDT bearing certificate image1 Original NACHI 7338BDT bearing certificate image2
